Surface Mounted Door Stay Range
The MICO Surface-Mounted Door Stay is a robust, stainless steel adjustable door stay designed to absorb the shocks that are caused by forcibly opening the door.
The door stays are made with easy adjustment in mind, with an adjustable fastener that can be adjusted to allow openings of between 90 to 110 degrees and a hold-open tension that can be easily adjusted on-site.
These stays are a highly recommended ancillary for doors that are frequently used, or for external doors subject to strong winds, storms, and other aggressive weather conditions.
The high-quality marine-grade stainless steel construction makes them particularly suited to coastal regions and other areas susceptible to corrosion, acid rain, and other hostile weather.
The MICO Surface-Mounted Door Stay range consists of the Medium Duty 100 Series and the Heavy Duty 200 series, both available in a range of different arm lengths to suit a variety of leaf widths and needs.
OPERATION
MICO Door Stays consist of two sets of steel brackets, one of which is fitted to the door itself or a reinforcement plate attached to the door leaf, and the other attached to the door frame.
Depending on the conditions the Door Stay needs to withstand, steel reinforcement plates that are at least 300 mm long, 40 mm wide and 6 mm thick are recommended to help distribute the various forces hitting the door and avoid potential deformation.
Please be aware that our door stays are not recommended for use on fire-rated doors.
FEATURES
Full stainless steel construction with a brushed finish.
A range of arm lengths from 400 mm to 700 mm to suit a wide range of doors and door frames.
Longer arm lengths available via special order.
BENEFITS
Heavy-duty marine-grade stainless steel construction designed to withstand extreme weather, corrosion and physical attack.
Adjustable degrees of opening whilst.
Robust in-built shock absorption system.
OPTIONS
We offer our range of door stays in an array of different arm lengths to suit particular door widths as part of two different ranges.
As both door stays are suitable for use with steel or timber doorsets, stainless steel machine screws (for steel doorset applications) or woodscrew fixings (for timber doorsets) are available on request.
M100 Series – The Medium Duty 100 Series door stays have a 12 mm diameter stainless steel arm suited for general use in strong weather.
H200 Series – The Heavy Duty 200 Series are designed for extremely wide or heavy doors, such as oversized plant entry, external security doors, cell doors and security doors, particularly in coastal regions or regions that commonly face gale force winds, violent opening or more abusive use than is typical.
Durable, reliable, and secure door control-discover the MICO Door Stay range.
Our Door Stay range is designed to reliably hold heavy-duty doorsets open.
The Door Stay is suitable for a wide range of applications. It can be used on doorsets in commercial or industrial facilities where doors need to remain open for deliveries or customer access. It is also suitable for more extreme installations that utilise heavy-duty doorsets or require resistance to hazardous conditions, such as warehouse doors and utility entrance doors at wind farms.
The full stainless steel construction is tested to EN 1670:GR5 for corrosion resistance, ensuring durability in corrosive environments. Engineered for exceptional shock absorption, the Door Stay withstands frequent daily use and helps protect your doors, walls, and personnel from accidental damage. A simple pull on the handle releases the latch and allows smooth door closure.
